Description
Features
1.Headlights:
Classic Scooter Headlight. Bright enough to light your way through those wide open roads. Provides a large area of coverage for nighttime driving.
2.Durable Seating:
Have an enjoyable ride resting on this very comfortably padded seat.
3.Floorboard:
The resistant material will allow you rest your foot.
4.Clear and Direct Instrument Panel:
You can easily and clearly view the speedometer, turn signals, fuel gauge and battery gauge making for a more efficient ride.
5.Dynamic Front Disc Brake:
Powerful and durable front disc provides excellent braking at any speed; giving you the safety you need.
6.Taillight:
Emitting bright light so all drivers behind you can see you even in the darkest of nights.
Assembly Information
Our vehicles come 90% assembled at the factory and fully tested prior to shipping. There is some parts assembly required depending on which model purchased.
Technical Specs
ENGINE / DRIVE TRAIN |
Displacement: |
50 cc |
Type: |
4 Stroke Single Cylinder |
|
Compression Ratio: |
10.5:1 |
|
Horsepower: |
2.95 HP - 7500 RPM |
|
Max Torque: |
2.5 N.m - 6000 RPM |
|
Cooling System: |
Air Cooled |
|
Transmission: |
C.V.T. |
|
Clutch: |
/ |
|
Drive: |
Belt |
|
Starter: |
Kick/Electrical Starter |
|
Ignition: |
CDI |
|
Spark Plug: |
A7RTC |
|
Battery Capacity: |
12V6Ah (closed type, maintenance-free) |
|
Top Speed: |
30 mph |
|
CHASSIS / SUSPENSION / BRAKES |
Frame: |
High Strength Ironic |
Front Suspension: |
Telescopic Fork |
|
Rear Suspension: |
Unit Swing |
|
Front Brakes: |
Disc (150 mm) |
|
Rear Brakes: |
Drum (110 mm) |
|
Front Tires: |
3.50-12 |
|
Rear Tires: |
3.50-12 |
|
Wheel: |
Aluminum |
|
CAPACITIES / DIMENSIONS |
Weight Capacity: |
209 Lbs |
Net Weight: |
163 Lbs |
|
Fuel: |
Unleaded (90 octanes or higher) |
|
Fuel Capacity: |
6L |
|
Ground Clearance: |
6.6 in |
|
Length: |
68 in |
|
Width: |
26.4 in |
|
Height: |
43.2 in |
|
Seat Height: |
29.6 in |
|
Wheelbase: |
48 in |
|
Age Recommendation: |
16+ |
|
ADDITIONAL INFO |
Government Certifications: |
EPA & DOT Approved, C.A.R.B. Approved for CA |
Warranty: |
Build by SYM with 24 Months Limited Warranty |
|
MPG: |
105 MPG* |
Specification
Vendor | BOOM |
---|---|
Shipping Rate | 199.9500 |
Assembly | Fully Assembled (Installation require on some bolt-on items) |
Engine | Air cooled,Single cylinder,4 Stroke |
Engine Type (ml) | 49 |
Starter | Kick / Electrical Starter |
Battery Type | 12V6Ah |
Gear | C.V.T. |
Transmission | Belt Drive |
Ignition | CDI |
Max Power | 2.95 HP - 7500 RPM |
Max Torque | 2.5 N.m - 6000 RPM |
How Fast | 30 |
Cooling System | Air Cooled |
Kill switch | No |
Speed limiter | No |
Fuel Type | Gas |
Fuel Capacity (Gal) | 1.6 |
Frame | High Strength Ironic |
Ground Clearance (inch) | 6.6 |
Wheelbase (inch) | 48 |
Brakes Front | Disc (150 mm) |
Brakes Rear | Drum (110 mm) |
Tires Front | 3.50-12 |
Tires Rear | 3.50-12 |
Front Suspension | Telescopic Fork |
Rear Suspension | Unit Swing |
Wheel Size | Aluminum |
N.W. (lbs) | 163 |
Overall Length (inch) | 68 |
Overall Width (inch) | 26.4 |
Overall Height (inch) | 43.2 |
Seat Height: (inch) | 29.6 |
Tools Kit | Yes |
CARB Approved | No |
MCO(Title) | Yes |
Low Price Guarantee | Yes |
Gallery
Scooter FAQ
Click Here >>FAQ
1. How long have Red Fox Powersports been in business?
A: We have been in the Power Sports industry since 2004 , We do have our own exclusive factory working with us. This will allow us to present exclusive NEW products every year.
2. Where is Red Fox Powersports located?
A: We are located in Southern California with full service capability. Address can be found on the website under office hour and location at the bottom of the page.
3. Can I place my order online by myself?
A: Yes, Red Fox Powersports has the most updated technology on website design, 100% secure shopping cart, self-checkout, user friendly search engine, Detail and accurate specification, exclusive photos and videos of the product. Our goal is to make sure our customer’s money is well spend.
4. Can I place my order over the phone?
A: Yes, contact us at and our well trained staff is ready to help you to pick the best one that is suitable for you. Although some time the phone calls could be busy and you may have to wait on the line, you can always reach us by using the live chat or send us a email (usually live chat is the faster route). To place phone order, please call 877-266-2148
5. How can I make sure the one that I want is in stock before I place my order?
A: You can contact us either by phone, live chat or email to confirm the availability before you place the order.
6. Why is there a 2nd color choice?
A: Due to large demand and limited quantity, a 2nd choice color will help your order to get process smooth incase the 1st choice color is just happen to be out at that moment. But if you absolute need your 1st choice color, just put the 2nd choice color as the same as your 1st choice color.
7. What is 80% and 85% package?
A: This means the package is a factory package which require assembly and fine tune (vary by models). If you are not a mechanic yourself, we strongly suggest you to take our PRO Fully Assembled with Ride Test Package.
8. How fast will I get my order if I pick the rush process?
A: If you select rush process we will ship your order out within 24-36 hours.
9. When can I expect my shipment?
A: This will depending on many factor such as the product, package that is choose, weather , destination and freight carrier schedule and your location, but under normal circumstance it should take anywhere around 5-10 business days.
10. I just placed my order, what should I expect from there now?
A: After you order has been placed, our customer service team will start process your order, they will first make sure your order complies with all security standard and then submit order to the shipping department for freight schedule. At the same time, warehouse will prepare your order for shipping too. The above procedure should be complete within 24-72hrs after you have placed the order. Once the freight carrier picked up your order then you can start track the package by using the tracking number provided by us to you via email.
