Description
Features
1.Headlights:
Bright enough to get you through any time in the evening. Beautifully designed to catch your eyes.
2.Durable Seating:
Have an enjoyable ride resting on this very comfortably padded seat.
3.Floorboard:
The resistant material will allow you rest your foot.
4.Electric/Kick Start:
With two ways to start your scooter; it is always great to have a reliable back-up in any situation.
5.Dynamic Front Disc Brake:
Powerful and durable front disc provides excellent braking at any speed; giving you the safety you need.
6.Taillight:
Emitting bright light so all drivers behind you can see you even in the darkest of nights.
Assembly Information
Our vehicles come 90% assembled at the factory and fully tested prior to shipping. There is some parts assembly required depending on which model purchased.
Technical Specs
ENGINE / DRIVE TRAIN |
Displacement: |
50 cc |
Type: |
4 Stroke Single Cylinder |
|
Compression Ratio: |
10.5:1 |
|
Horsepower: |
2.95 HP - 7500 RPM |
|
Max Torque: |
2.5 N.m - 6000 RPM |
|
Cooling System: |
Air Cooled |
|
Transmission: |
C.V.T. |
|
Clutch: |
/ |
|
Drive: |
Belt |
|
Starter: |
Kick/Electrical Starter |
|
Ignition: |
CDI |
|
Spark Plug: |
A7RTC |
|
Battery Capacity: |
12V7Ah (closed type, maintenance-free) |
|
Top Speed: |
30 mph |
|
CHASSIS / SUSPENSION / BRAKES |
Frame: |
High Strength Ironic |
Front Suspension: |
Telescopic Fork |
|
Rear Suspension: |
Unit Swing |
|
Front Brakes: |
Disc (180 mm) |
|
Rear Brakes: |
Drum (110 mm) |
|
Front Tires: |
3.50-10 |
|
Rear Tires: |
3.50-10 |
|
Wheel: |
Aluminum |
|
CAPACIITIES / DIMENSIONS |
Weight Capacity: |
209 Lbs |
Net Weight: |
183 Lbs |
|
Fuel: |
Unleaded (90 octane or higher) |
|
Fuel Capacity: |
6L |
|
Ground Clearance: |
6.4in |
|
Length: |
74.4 in |
|
Width: |
30.6 in |
|
Height: |
40.8 in |
|
Seat Height: |
31.2 in |
|
Wheelbase: |
52 in |
|
Age Recommendation: |
16+ |
|
Specification
Vendor | BOOM |
---|---|
Shipping Rate | 199.9500 |
Assembly | 85% Assemble (need to assemble front wheel, handle bar, mirror, battery and etc) |
Engine | Air cooled,Single cylinder,4 Stroke |
Engine Type (ml) | 49.7 |
Starter | Kick / Electrical Starter |
Battery Type | 12V7Ah |
Gear | C.V.T. |
Transmission | Belt Drive |
Ignition | CDI |
Max Power | 2.95 HP - 7500 RPM |
Max Torque | 2.5 N.m - 6000 RPM |
How Fast | Est 30+ (depending on rider's weight and road condition) |
Cooling System | Air Cooled |
Kill switch | Yes |
Speed limiter | Yes |
Fuel Type | Gas |
Fuel Capacity (Gal) | 1.6 |
Consumption | Est 100+ |
Frame | High Strength Ironic |
Ground Clearance (inch) | 6.4 |
Wheelbase (inch) | 52 |
Brakes Front | Disc (180 mm) |
Brakes Rear | Drum (110 mm) |
Tires Front | 3.50-10 |
Tires Rear | 3.50-10 |
Front Suspension | Telescopic Fork |
Rear Suspension | Unit Swing |
Wheel Size | Aluminum |
N.W. (lbs) | 183 |
Overall Length (inch) | 74.4 |
Overall Width (inch) | 30.6 |
Overall Height (inch) | 40.8 |
Seat Height: (inch) | 31.2 |
Tools Kit | Yes |
CARB Approved | No |
MCO(Title) | Yes |
Low Price Guarantee | Yes |
